LYC bearing

LYC bearing
LYC bearings are classified as:
LYC deep groove ball bearing, LYC self aligning ball bearing, LYC thrust ball bearing, LYC angular contact ball bearing, LYC self aligning roller bearing
Thrust ball bearing composition of thrust ball bearing:
The thrust ball bearing consists of three parts: seat ring, shaft ring and steel ball cage assembly.
The shaft ring matched with the shaft and the seat ring matched with the shell.
Type of thrust ball bearing:
The receiving force is divided into one-way thrust ball bearing and two-way thrust ball bearing.
One way thrust ball bearing can bear one-way axial load.
Two way thrust ball bearing can bear two-way axial load. Two way thrust ball bearing, in which the ring is matched with the shaft. The bearing with spherical mounting surface of the race has the function of adjusting the center, which can reduce the influence of installation error.
The thrust ball bearing can not bear radial load, and the limit speed is low. The thrust ball bearing is only applicable to the parts with one side axial load and low rotation speed, such as crane hook, instant water pump, instant centrifuge, Jack, low-speed reducer, etc. The shaft ring, seat ring and rolling element of the bearing are separated and can be installed and disassembled separately.
Angular contact ball bearing
(angular contact ball bearings) can bear both radial and axial loads. It can work at high speed. The larger the contact angle is, the higher the axial bearing capacity is. High precision and high-speed bearings usually have a 15 degree contact angle. Under the action of axial force, the contact angle will increase. Single row angular contact ball bearing: machine tool spindle, high frequency motor, gas turbine, centrifugal separator, small car front wheel, differential pinion shaft
Double row angular contact ball bearing: oil pump, roots blower, air compressor, various transmissions, fuel injection pump, printing machinery.
